The EZ-TAG3 IP55 External Key Pad for Lock Control from ESP is a programmable door access control unit featuring durable construction and modern aesthetics; making it a perfect addition to any access control system.
Users approach the keypad and enter a four-digit code to activate one of the EZ-TAG3s on board relays. These relays are used to carry power from a 12vdc power supply to an appropriate door release. The EZ-TAG3 can be used to operate two separate electronic locks. In addition, 2 user groups can be set up allowing specific area access. The EZ-TAG3 can also be used as a doorbell for visitors.
Programming the system is kept as simple as possible, all functions are carried out at the keypad itself, the unit is totally self-contained, and no PC or laptop is required.
The EZ-TAG3 can be installed as a new stand-alone access control system simply by adding a 12vdc power supply and suitable door release or it can be used to upgrade an existing system to allow entry of pre-authorised visitors such as staff without bothering reception. In this case, the power supply and door release of the existing system is usually suitable for use with the EZ-TAG3.
- Easy install
- Simple self-contained programming
- Fail-safe or secure options from the power supply
- Combined keypad and controller
- Weatherproof IP55 rated
- Durable Metal Construction
- Backlit Blue LED Keypad
- Activation Notification LED
- 2 Relay Outputs
- 2 User Groups
- Doorbell Function
- Anti Tamper Option
- Complete with 10 tags
- DC Input: 12-24 Volts
- AC Input: 12-24 Volts
- Standby Current: 80ma
- Operating Current (Without Lock): 110ma @ 12 volts DC
- Working Temperature: -20°C to +50°C
- IP Rating: IP65
- Dimensions: 152 x 45 x 25mm
Comes with a 3 Year Manufacturer's Warranty
To view the manufacturer's manual for this product, Click Here
