Description
Type A RCD for AC residual current and pulsating DC up to 6 mA. Suitable for equipment with electronic components such as IT equipment. Passive (latching) type, which will automatically reset after a power outage, without the need for manual resetting. - Tripping current (IΔn): 30mA - Trip time @ IΔn: 40ms - Minimum mounting box depth: 35mm
Technical Specification:
Projection (mm): 12Min. Mounting Box Depth (mm): 35mm
Construction: Thermoset resin
Finish: White
Class: I
IP Rating: IP20
Primary Voltage: 230V 50Hz
Earth Terminal: Yes
Terminal: Captive
Dimensions: Height: 86mm
Weight: 0.157Kg
Warranty: 2 Years
